UM positioning workbench series

Published:

2022-08-15 08:59

Introduction to UM Positioning Workbench Series

UM120

Overall dimensions

technical parameter

parameter	UM120-01X01YR-3
parameter	X	Y	R
Peak thrust (torque)	80N	80N	2.0 N.m
Continuous thrust (torque)	15N	15N	0.4 N.m
Maximum transportable mass	5.9Kg	5.9Kg	6.8Kg
Effective travel (angle)	20mm	20mm	60°
resolving power	0.1um	0.1um	0.36角秒
Maximum speed	400mm/s	400mm/s	400°/s
Repetitive positioning accuracy	±0.5um	±0.5um	±0.8角秒

UM200

Overall dimensions

technical parameter

parameter	UM200-01X01YR-3
parameter	X	Y	R
Peak thrust (torque)	400N	400N	4.0 N.m
Continuous thrust (torque)	70N	70N	1.2 N.m
Maximum transportable mass	30Kg	30Kg	12.3Kg
Effective travel (angle)	25mm	25mm	280°
resolving power	0.1um	0.1um	0.25角秒
Maximum speed	400mm/s	400mm/s	270°/s
Repetitive positioning accuracy	±0.5um	±0.5um	±0.5角秒
